  • Cylindrical expansion tank
  • Continuous water flow with constant pressure
Article number: 071106
Barcode: 3800972015784
Brand: Raider Garden Tools

pictogram
pictogram
pictogram
pictogram
pictogram
pictogram
pictogram
pictogram
Description
Booster pump are used for automatic pump control depending on water consumption. It is typical for them that they smooth out the inevitable impulses of the water jet when starting and stopping the pump.

The RD-WP800S model can be used both for mobile use and for stationary water supply where needed.
Pumps of this type are characterized by a cylindrical vessel in which the expansion vessel (called hydrophore) plays the role of an additional volume for water.

  • Maximum water flow 53 l / min

  • Pumping height reaches 40 m

  • Suction depth 7 m

  • Built-in air-cooling system

  • Features
    Main characteristics
    Rated voltage type Corded - Electrical Grid
    Maximum delivery height 40 m
    Maximum working pressure 3 bar
    Drive shaft material Steel
    Pump material Steel
    Rated input power 800 W
    Discharge port 1 Inch
    Additional characteristics
    Maximum delivery rate 3180 l/h
    Cable length 1.5 m
    Maximum suction depth 8 m
    Tank material Steel
    Tank capacity ~ 20 l
    Suction apature 1 Inch
