Outer disc diameter (mm)
315 mm
Inner disc diameter (mm)
30 mm
Disc teeth (pcs.)
24 pcs
Maximum no- load speed (min-1)
2990 min-1
Maximum material width @ mitre fence (mm)
250 mm
Maximum material width @ parallel guide fence (mm)
340 mm
Rated input power (W)
4200 W
Rated voltage (V)
400 V
Output power (W)
3500 W
Working height (mm)
850 mm
Size (mm)
1700x700x1000 mm
Cutting speed (m/s)
50 m/s
Rated voltage type
Corded - Electrical Grid
Maximum cutting depth @ 90° / 45° (mm)
85/53 mm
Material of the table
Galvanized Sheet Metal
Support surface dimensions (mm)
800x600 mm
Circular saw disc tilt (°)
0-45 °
Description
-

Features
Main characteristics
Circular saw disc tilt (°) 0-45 °
Size (mm) 1700x700x1000 mm
Disc teeth (pcs.) 24 pcs
Maximum material width @ mitre fence (mm) 250 mm
Maximum no- load speed (min-1) 2990 min-1
Inner disc diameter (mm) 30 mm
Outer disc diameter (mm) 315 mm
Maximum material width @ parallel guide fence (mm) 340 mm
Output power (W) 3500 W
Rated voltage (V) 400 V
Rated input power (W) 4200 W
Cutting speed (m/s) 50 m/s
Support surface dimensions (mm) 800x600 mm
Maximum cutting depth @ 90° / 45° (mm) 85/53 mm
Working height (mm) 850 mm
Rated voltage type Corded - Electrical Grid
Material of the table Galvanized Sheet Metal
Equipment
Твърдосплавен диск (24 зъба)1 бр.
Удължение на плота1 бр.
Приспособления за прахоулавяне1 бр.
Избутвач1 бр.
Успореден водач1 бр.
Files
Presenter Download
User manual Download
