Outer disc diameter (mm)
450 mm
Inner disc diameter (mm)
30 mm
Disc teeth (pcs.)
32 pcs
Maximum no- load speed (min-1)
2750 min-1
Maximum material width @ mitre fence (mm)
260 mm
Maximum material width @ parallel guide fence (mm)
300 mm
Maximum detail width @ miter fence (mm)
260 mm
Maximum cutting width with an additional table (mm)
1300 mm
Maximum material width @ parallel rip fence (mm)
300 mm
Rated input power (W)
5500 W
Rated voltage (V)
400 V
Output power (W)
3200 W
Working height (mm)
850 mm
Size (mm)
1830x750x1020 mm
Cutting speed (m/s)
68 m/s
Rated voltage type
Corded - Electrical Grid
Maximum cutting depth @ 90° / 45° (mm)
140/0 mm
Material of the table
Galvanized Sheet Metal
Support surface dimensions (mm)
1030x660 mm
Description
-

Features
Main characteristics
Outer disc diameter (mm) 450 mm
Inner disc diameter (mm) 30 mm
Disc teeth (pcs.) 32 pcs
Maximum no- load speed (min-1) 2750 min-1
Maximum material width @ mitre fence (mm) 260 mm
Maximum material width @ parallel guide fence (mm) 300 mm
Maximum detail width @ miter fence (mm) 260 mm
Maximum cutting width with an additional table (mm) 1300 mm
Maximum material width @ parallel rip fence (mm) 300 mm
Rated input power (W) 5500 W
Rated voltage (V) 400 V
Output power (W) 3200 W
Working height (mm) 850 mm
Size (mm) 1830x750x1020 mm
Cutting speed (m/s) 68 m/s
Rated voltage type Corded - Electrical Grid
Maximum cutting depth @ 90° / 45° (mm) 140/0 mm
Material of the table Galvanized Sheet Metal
Support surface dimensions (mm) 1030x660 mm
Equipment
Твърдосплавен диск (32 зъба)1 бр.
Удължение на плота1 бр.
Кука1 бр.
Избутвач1 бр.
Успореден водач1 бр.
Files
Presenter Download
User manual Download
