Spanners with ratchet 10mm CR-V TMP
Spanners with ratchet 10mm CR-V TMP
- Made of high quality chrome vanadium steel
- Extended arm
Article number: 231950
Barcode: 3800972000278
Brand: Top Master Pro
Barcode: 3800972000278
Brand: Top Master Pro
Download:
Warranty (years)
30 years
Wrench thickness W1 (mm)
8.3 mm
Wrench thickness W2 (mm)
7.8 mm
Length (mm)
295 mm
Material
Cr-V
Generation
2nd generation
Size (mm)
10 mm
Ratchet mechanism (tooth)
72 tooth
Spanner width D1 (mm)
16 mm
Spanner width D2 (mm)
21.5 mm
Coating
Mirror Polish
Series
| Art. Number | Product | Coating | Generation | Length (mm) | Material | Ratchet mechanism (tooth) | Size (mm) | Spanner width D1 (mm) | Spanner width D2 (mm) | Warranty (years) | Wrench thickness W1 (mm) | Wrench thickness W2 (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 231950 |
Top Master Pro Spanners with ratchet 10mm CR-V TMP |
Mirror Polish | 2nd generation | 295 mm | Cr-V | 72 tooth | 10 mm | 16 mm | 21.5 mm | 30 years | 8.3 mm | 7.8 mm |
| 231951 |
Top Master Pro Spanners with ratchet 12mm CR-V TMP |
Mirror Polish | 2nd generation | 331 mm | Cr-V | 72 tooth | 12 mm | 19.5 mm | 25 mm | 30 years | 10 mm | 8.8 mm |
| 231952 |
Top Master Pro Spanners with ratchet 13mm CR-V TMP |
Mirror Polish | 2nd generation | 351 mm | Cr-V | 72 tooth | 13 mm | 20.8 mm | 26.4 mm | 30 years | 10.5 mm | 9.1 mm |
| 231953 |
Top Master Pro Spanners with ratchet 14mm CR-V TMP |
Mirror Polish | 2nd generation | 371 mm | Cr-V | 72 tooth | 14 mm | 22 mm | 28 mm | 30 years | 11 mm | 9.4 mm |
| 231954 |
Top Master Pro Spanners with ratchet 15mm CR-V TMP |
Mirror Polish | 2nd generation | 378 mm | Cr-V | 72 tooth | 15 mm | 23.5 mm | 30 mm | 30 years | 11.5 mm | 9.8 mm |
| 231955 |
Top Master Pro Spanners with ratchet 16mm CR-V TMP |
Mirror Polish | 2nd generation | 393 mm | Cr-V | 72 tooth | 16 mm | 25 mm | 31.5 mm | 30 years | 12 mm | 10.2 mm |
| 231956 |
Top Master Pro Spanners with ratchet 17mm CR-V TMP |
Mirror Polish | 2nd generation | 412 mm | Cr-V | 72 tooth | 17 mm | 26.3 mm | 33 mm | 30 years | 12.8 mm | 10.5 mm |
Description
The professional hand tools of Topmaster combine exceptional design, quality & long service life.
Topmaster's 10 mm Spanners with ratchet features:
High-quality chrome-vanadium (CR-V) steel, giving great strength
Mirror-polished finish
Precise ratchet mechanism with 72 teeth
Topmaster's 10 mm Spanners with ratchet features:
Features
Main characteristics
| Size (mm) | 10 mm |
| Spanner width D1 (mm) | 16 mm |
| Spanner width D2 (mm) | 21.5 mm |
| Length (mm) | 295 mm |
| Generation | 2nd generation |
| Warranty (years) | 30 years |
| Wrench thickness W2 (mm) | 7.8 mm |
| Ratchet mechanism (tooth) | 72 tooth |
| Wrench thickness W1 (mm) | 8.3 mm |
| Material | Cr-V |
| Coating | Mirror Polish |
