Outer disc diameter (mm)
315 mm
Inner disc diameter (mm)
30 mm
Cutting depth (mm)
0|120 mm
Cable length (m)
2.1 m
Disc teeth (pcs.)
84 pcs
Maximum no- load speed (min-1)
4100 min-1
Maximum cutting speed (m/s)
68 m/s
Maximum workpiece width (mm)
320 mm
Rated input power (W)
2200 W
Rated input power s1 100% (W)
1600 W
Rated input power s6 20% (W)
2200 W
Rated voltage (V)
230 V
Load speed (min-1)
4100 min-1
Size (mm)
950x765x660 mm
Cutting speed (m/s)
68 m/s
Rated voltage type
Corded - Electrical Grid
Cutting width (mm)
320 mm
Turntable setting left / right (°)
47/60 °
Cutting capacity 45° / -45° (mm)
223x76 mm
Cutting capacity 90° / -90° (mm)
320x120 mm
Maximum cutting depth @ 90° / 45° (mm)
120/76 mm
Maximum cutting width @ 90° / 45° (mm)
320/223 mm
Saw blade tilt left / right (°)
46/46 °
Description
-

Features
Main characteristics
Cutting depth (mm) 0|120 mm
Maximum cutting depth @ 90° / 45° (mm) 120/76 mm
Rated input power s1 100% (W) 1600 W
Cable length (m) 2.1 m
Rated input power (W) 2200 W
Cutting capacity 45° / -45° (mm) 223x76 mm
Rated voltage (V) 230 V
Inner disc diameter (mm) 30 mm
Outer disc diameter (mm) 315 mm
Maximum cutting width @ 90° / 45° (mm) 320/223 mm
Maximum workpiece width (mm) 320 mm
Cutting capacity 90° / -90° (mm) 320x120 mm
Maximum no- load speed (min-1) 4100 min-1
Saw blade tilt left / right (°) 46/46 °
Turntable setting left / right (°) 47/60 °
Maximum cutting speed (m/s) 68 m/s
Disc teeth (pcs.) 84 pcs
Size (mm) 950x765x660 mm
Rated voltage type Corded - Electrical Grid
Equipment
Твърдосплавен диск (84 зъба)1 бр.
Адаптор1 бр.
Уширения на плота2 бр.
Стяга1 бр.
Files
Presenter Download
User manual Download
