  • The head of the key is inclined 15 °, convenient for work in inaccessible places
  • Made of high quality chrome vanadium steel
  • Fully polished
Article number: 230511
Barcode: 3800123111600
Brand: Top Master Pro

DIN
3113
Wrench thickness W1 (mm)
6.2 mm
Wrench thickness W2 (mm)
9.3 mm
Length (mm)
200 mm
Material
Cr-V
Offset ring @ (°)
15 °
Generation
1st generation
Size (mm)
16 mm
Reverse
No
Spanner width D1 (mm)
34.9 mm
Spanner width D2 (mm)
24 mm
Coating
Mirror Polish
Series
Art. Number Product Coating DIN Generation Length (mm) Material Offset ring @ (°) Reverse Size (mm) Spanner width D1 (mm) Spanner width D2 (mm) Wrench thickness W1 (mm) Wrench thickness W2 (mm)
230501 Top Master Pro
Combination spanners 6mm CR-V TMP
Mirror Polish 3113 1st generation 100 mm Cr-V 15 ° No 6 mm 14.2 mm 11 mm 3.8 mm 5.5 mm
230502 Top Master Pro
Combination spanners 7mm CR-V TMP
Mirror Polish 3113 1st generation 110 mm Cr-V 15 ° No 7 mm 16 mm 12.6 mm 4.6 mm 5.2 mm
230503 Top Master Pro
Combination spanners 8mm CR-V TMP
Mirror Polish 3113 1st generation 120 mm Cr-V 15 ° No 8 mm 18.2 mm 12.8 mm 4.3 mm 6.5 mm
230504 Top Master Pro
Combination spanners 9mm CR-V TMP
Mirror Polish 3113 1st generation 130 mm Cr-V 15 ° No 9 mm 20.1 mm 14.9 mm 5.3 mm 7.5 mm
230505 Top Master Pro
Combination spanners 10mm CR-V TMP
Mirror Polish 3113 1st generation 140 mm Cr-V 15 ° No 10 mm 20.2 mm 15.5 mm 6.6 mm 8.1 mm
230506 Top Master Pro
Combination spanners 11mm CR-V TMP
Mirror Polish 3113 1st generation 150 mm Cr-V 15 ° No 11 mm 24.3 mm 17.6 mm 5.5 mm 8.3 mm
230507 Top Master Pro
Combination spanners 12mm CR-V TMP
Mirror Polish 3113 1st generation 160 mm Cr-V 15 ° No 12 mm 26 mm 19.4 mm 4.9 mm 7.7 mm
230508 Top Master Pro
Combination spanners 13mm CR-V TMP
Mirror Polish 3113 1st generation 170 mm Cr-V 15 ° No 13 mm 28.8 mm 20.5 mm 5.9 mm 7.85 mm
230509 Top Master Pro
Combination spanners 14mm CR-V TMP
Mirror Polish 3113 1st generation 180 mm Cr-V 15 ° No 14 mm 31 mm 21.8 mm 6.3 mm 9 mm
230510 Top Master Pro
Combination spanners 15mm CR-V TMP
Mirror Polish 3113 1st generation 190 mm Cr-V 15 ° No 15 mm 30.9 mm 22.7 mm 5.9 mm 9.2 mm
230511 Top Master Pro
Combination spanners 16mm CR-V TMP
Mirror Polish 3113 1st generation 200 mm Cr-V 15 ° No 16 mm 34.9 mm 24 mm 6.2 mm 9.3 mm
230512 Top Master Pro
Combination spanners 17mm CR-V TMP
Mirror Polish 3113 1st generation 210 mm Cr-V 15 ° No 17 mm 35.1 mm 25.6 mm 6.2 mm 9.3 mm
230513 Top Master Pro
Combination spanners 18mm CR-V TMP
Mirror Polish 3113 1st generation 220 mm Cr-V 15 ° No 18 mm 37.7 mm 27.2 mm 6.6 mm 9.7 mm
230514 Top Master Pro
Combination spanners 19mm CR-V TMP
Mirror Polish 3113 1st generation 230 mm Cr-V 15 ° No 19 mm 38.2 mm 27.6 mm 7 mm 10.8 mm
230515 Top Master Pro
Combination spanners 20mm CR-V TMP
Mirror Polish 3113 1st generation 240 mm Cr-V 15 ° No 20 mm 42.5 mm 30 mm 7.1 mm 11.4 mm
230516 Top Master Pro
Combination spanners 21mm CR-V TMP
Mirror Polish 3113 1st generation 250 mm Cr-V 15 ° No 21 mm 43.2 mm 31.5 mm 7.2 mm 11.9 mm
230517 Top Master Pro
Combination spanners 22mm CR-V TMP
Mirror Polish 3113 1st generation 260 mm Cr-V 15 ° No 22 mm 45.1 mm 33.8 mm 7.8 mm 11.8 mm
230518 Top Master Pro
Combination spanners 23mm CR-V TMP
Mirror Polish 3113 1st generation 265 mm Cr-V 15 ° No 23 mm 47.1 mm 33 mm 6.8 mm 11.8 mm
230519 Top Master Pro
Combination spanners 24mm CR-V TMP
Mirror Polish 3113 1st generation 280 mm Cr-V 15 ° No 24 mm 51.7 mm 35.1 mm 7.5 mm 12.2 mm
230520 Top Master Pro
Combination spanners 27mm CR-V TMP
Mirror Polish 3113 1st generation 310 mm Cr-V 15 ° No 27 mm 57.5 mm 39.3 mm 8.3 mm 13.5 mm
230521 Top Master Pro
Combination spanners 30mm CR-V TMP
Mirror Polish 3113 1st generation 340 mm Cr-V 15 ° No 30 mm 61.8 mm 43.5 mm 9.3 mm 14.8 mm
230522 Top Master Pro
Combination spanners 32mm CR-V TMP
Mirror Polish 3113 1st generation 360 mm Cr-V 15 ° No 32 mm 67 mm 46.7 mm 10.2 mm 16.8 mm
230527 Top Master Pro
Combination spanners 36mm CR-V TMP
Mirror Polish 3113 1st generation 383 mm Cr-V 15 ° No 36 mm 73 mm 54 mm 12 mm 20 mm
230528 Top Master Pro
Combination spanners 41mm CR-V TMP
Mirror Polish 3113 1st generation 435 mm Cr-V 15 ° No 41 mm 82 mm 60 mm 14 mm 21 mm
230529 Top Master Pro
Combination spanners 46mm CR-V TMP
Mirror Polish 3113 1st generation 538 mm Cr-V 15 ° No 46 mm 97 mm 73 mm 16 mm 24 mm
Description
The professional hand tools of Topmaster combine exceptional design, quality & long service life.

Topmaster 16 mmCombination spanner features:

  • High quality chrome-vanadium (CR-V) steel, great strength

  • Chrome-nickel anti-corrosion coating
  • >
  • The spanner head has an inclination of 15 ° - convenient for work in hard-to-reach places

  • Fully polished finish

  • Standardization: DIN 3113

  • Features
    Main characteristics
    Offset ring @ (°) 15 °
    Size (mm) 16 mm
    Generation 1st generation
    Length (mm) 200 mm
    Spanner width D2 (mm) 24 mm
    DIN 3113
    Spanner width D1 (mm) 34.9 mm
    Wrench thickness W1 (mm) 6.2 mm
    Wrench thickness W2 (mm) 9.3 mm
    Material Cr-V
    Coating Mirror Polish
    Reverse No
