  • The head of the key is inclined 15 °, convenient for work in inaccessible places
  • Made of high quality chrome vanadium steel
  • Fully polished
Article number: 230504
Barcode: 3800123111532
Brand: Top Master Pro

DIN
3113
Wrench thickness W1 (mm)
5.3 mm
Wrench thickness W2 (mm)
7.5 mm
Length (mm)
130 mm
Material
Cr-V
Offset ring @ (°)
15 °
Generation
1st generation
Size (mm)
9 mm
Reverse
No
Spanner width D1 (mm)
20.1 mm
Spanner width D2 (mm)
14.9 mm
Coating
Mirror Polish
Series
Art. Number Product Coating DIN Generation Length (mm) Material Offset ring @ (°) Reverse Size (mm) Spanner width D1 (mm) Spanner width D2 (mm) Wrench thickness W1 (mm) Wrench thickness W2 (mm)
230501 Top Master Pro
Combination spanners 6mm CR-V TMP
Mirror Polish 3113 1st generation 100 mm Cr-V 15 ° No 6 mm 14.2 mm 11 mm 3.8 mm 5.5 mm
230502 Top Master Pro
Combination spanners 7mm CR-V TMP
Mirror Polish 3113 1st generation 110 mm Cr-V 15 ° No 7 mm 16 mm 12.6 mm 4.6 mm 5.2 mm
230503 Top Master Pro
Combination spanners 8mm CR-V TMP
Mirror Polish 3113 1st generation 120 mm Cr-V 15 ° No 8 mm 18.2 mm 12.8 mm 4.3 mm 6.5 mm
230504 Top Master Pro
Combination spanners 9mm CR-V TMP
Mirror Polish 3113 1st generation 130 mm Cr-V 15 ° No 9 mm 20.1 mm 14.9 mm 5.3 mm 7.5 mm
230505 Top Master Pro
Combination spanners 10mm CR-V TMP
Mirror Polish 3113 1st generation 140 mm Cr-V 15 ° No 10 mm 20.2 mm 15.5 mm 6.6 mm 8.1 mm
230506 Top Master Pro
Combination spanners 11mm CR-V TMP
Mirror Polish 3113 1st generation 150 mm Cr-V 15 ° No 11 mm 24.3 mm 17.6 mm 5.5 mm 8.3 mm
230507 Top Master Pro
Combination spanners 12mm CR-V TMP
Mirror Polish 3113 1st generation 160 mm Cr-V 15 ° No 12 mm 26 mm 19.4 mm 4.9 mm 7.7 mm
230508 Top Master Pro
Combination spanners 13mm CR-V TMP
Mirror Polish 3113 1st generation 170 mm Cr-V 15 ° No 13 mm 28.8 mm 20.5 mm 5.9 mm 7.85 mm
230509 Top Master Pro
Combination spanners 14mm CR-V TMP
Mirror Polish 3113 1st generation 180 mm Cr-V 15 ° No 14 mm 31 mm 21.8 mm 6.3 mm 9 mm
230510 Top Master Pro
Combination spanners 15mm CR-V TMP
Mirror Polish 3113 1st generation 190 mm Cr-V 15 ° No 15 mm 30.9 mm 22.7 mm 5.9 mm 9.2 mm
230511 Top Master Pro
Combination spanners 16mm CR-V TMP
Mirror Polish 3113 1st generation 200 mm Cr-V 15 ° No 16 mm 34.9 mm 24 mm 6.2 mm 9.3 mm
230512 Top Master Pro
Combination spanners 17mm CR-V TMP
Mirror Polish 3113 1st generation 210 mm Cr-V 15 ° No 17 mm 35.1 mm 25.6 mm 6.2 mm 9.3 mm
230513 Top Master Pro
Combination spanners 18mm CR-V TMP
Mirror Polish 3113 1st generation 220 mm Cr-V 15 ° No 18 mm 37.7 mm 27.2 mm 6.6 mm 9.7 mm
230514 Top Master Pro
Combination spanners 19mm CR-V TMP
Mirror Polish 3113 1st generation 230 mm Cr-V 15 ° No 19 mm 38.2 mm 27.6 mm 7 mm 10.8 mm
230515 Top Master Pro
Combination spanners 20mm CR-V TMP
Mirror Polish 3113 1st generation 240 mm Cr-V 15 ° No 20 mm 42.5 mm 30 mm 7.1 mm 11.4 mm
230516 Top Master Pro
Combination spanners 21mm CR-V TMP
Mirror Polish 3113 1st generation 250 mm Cr-V 15 ° No 21 mm 43.2 mm 31.5 mm 7.2 mm 11.9 mm
230517 Top Master Pro
Combination spanners 22mm CR-V TMP
Mirror Polish 3113 1st generation 260 mm Cr-V 15 ° No 22 mm 45.1 mm 33.8 mm 7.8 mm 11.8 mm
230518 Top Master Pro
Combination spanners 23mm CR-V TMP
Mirror Polish 3113 1st generation 265 mm Cr-V 15 ° No 23 mm 47.1 mm 33 mm 6.8 mm 11.8 mm
230519 Top Master Pro
Combination spanners 24mm CR-V TMP
Mirror Polish 3113 1st generation 280 mm Cr-V 15 ° No 24 mm 51.7 mm 35.1 mm 7.5 mm 12.2 mm
230520 Top Master Pro
Combination spanners 27mm CR-V TMP
Mirror Polish 3113 1st generation 310 mm Cr-V 15 ° No 27 mm 57.5 mm 39.3 mm 8.3 mm 13.5 mm
230521 Top Master Pro
Combination spanners 30mm CR-V TMP
Mirror Polish 3113 1st generation 340 mm Cr-V 15 ° No 30 mm 61.8 mm 43.5 mm 9.3 mm 14.8 mm
230522 Top Master Pro
Combination spanners 32mm CR-V TMP
Mirror Polish 3113 1st generation 360 mm Cr-V 15 ° No 32 mm 67 mm 46.7 mm 10.2 mm 16.8 mm
230527 Top Master Pro
Combination spanners 36mm CR-V TMP
Mirror Polish 3113 1st generation 383 mm Cr-V 15 ° No 36 mm 73 mm 54 mm 12 mm 20 mm
230528 Top Master Pro
Combination spanners 41mm CR-V TMP
Mirror Polish 3113 1st generation 435 mm Cr-V 15 ° No 41 mm 82 mm 60 mm 14 mm 21 mm
230529 Top Master Pro
Combination spanners 46mm CR-V TMP
Mirror Polish 3113 1st generation 538 mm Cr-V 15 ° No 46 mm 97 mm 73 mm 16 mm 24 mm
Description
The professional hand tools of Topmaster combine exceptional design, quality & long service life.

Topmaster Combination spanners 9 mm features:

  • High qualiy chrome- vanadium steel (Cr-V) , for great durability

  • Chrome-nickel anti-corrosion coating

  • The spanner head has an inclination of 15 ° - convenient for work in hard-to-reach places

  • Fully polished finish

  • Standardization: DIN 3113

  • Features
    Main characteristics
    Length (mm) 130 mm
    Spanner width D2 (mm) 14.9 mm
    Offset ring @ (°) 15 °
    Generation 1st generation
    Spanner width D1 (mm) 20.1 mm
    DIN 3113
    Wrench thickness W1 (mm) 5.3 mm
    Wrench thickness W2 (mm) 7.5 mm
    Size (mm) 9 mm
    Material Cr-V
    Coating Mirror Polish
    Reverse No
