  • Made of chrome vanadium steel
  • Polished head
Article number: 230733
Barcode: 3800123172359
Brand: Gadget

Wrench thickness W1 (mm)
8.9 mm
Wrench thickness W2 (mm)
5.9 mm
Length (mm)
200 mm
Material
Cr-V
Offset ring @ (°)
15 °
Size (mm)
16 mm
Reverse
No
Spanner width D1 (mm)
24.2 mm
Spanner width D2 (mm)
33 mm
Coating
Matte
Series
Art. Number Product Coating Length (mm) Material Offset ring @ (°) Reverse Size (mm) Spanner width D1 (mm) Spanner width D2 (mm) Wrench thickness W1 (mm) Wrench thickness W2 (mm)
230723 Gadget
Combination Spanners CR-V 6mm GD
Matte 100 mm Cr-V 15 ° No 6 mm 10.5 mm 14.3 mm 5.5 mm 4 mm
230724 Gadget
Combination Spanners CR-V 7mm GD
Matte 110 mm Cr-V 15 ° No 7 mm 11.9 mm 15.8 mm 5.5 mm 3.8 mm
230725 Gadget
Combination Spanners CR-V 8mm GD
Matte 120 mm Cr-V 15 ° No 8 mm 12.7 mm 13.5 mm 5.7 mm 3.8 mm
230726 Gadget
Combination Spanners CR-V 9mm GD
Matte 130 mm Cr-V 15 ° No 9 mm 14.3 mm 19.7 mm 5.7 mm 4.2 mm
230727 Gadget
Combination Spanners CR-V 10mm GD
Matte 140 mm Cr-V 15 ° No 10 mm 15.8 mm 22.2 mm 6.9 mm 4.2 mm
230728 Gadget
Combination Spanners CR-V 11mm GD
Matte 150 mm Cr-V 15 ° No 11 mm 17.5 mm 23.5 mm 6.9 mm 4.8 mm
230729 Gadget
Combination Spanners CR-V 12mm GD
Matte 160 mm Cr-V 15 ° No 12 mm 18.6 mm 25.7 mm 7 mm 5.6 mm
230730 Gadget
Combination spanners CR-V 13mm GD
Matte 170 mm Cr-V 15 ° No 13 mm 20.6 mm 27 mm 7.9 mm 5.8 mm
230731 Gadget
Combination spanners CR-V 14mm GD
Matte 180 mm Cr-V 15 ° No 14 mm 22.1 mm 30 mm 8.5 mm 5.9 mm
230732 Gadget
Combination spanners CR-V 15mm GD
Matte 190 mm Cr-V 15 ° No 15 mm 23.7 mm 31.7 mm 8.9 mm 5.9 mm
230733 Gadget
Combination spanners CR-V 16mm GD
Matte 200 mm Cr-V 15 ° No 16 mm 24.2 mm 33 mm 8.9 mm 5.9 mm
230734 Gadget
Combination spanners CR-V 17mm GD
Matte 210 mm Cr-V 15 ° No 17 mm 26.1 mm 35.6 mm 9.2 mm 6.7 mm
230735 Gadget
Combination spanners CR-V 18mm GD
Matte 220 mm Cr-V 15 ° No 18 mm 27.9 mm 37.8 mm 9.5 mm 6.7 mm
230736 Gadget
Combination spanners CR-V 19mm GD
Matte 230 mm Cr-V 15 ° No 19 mm 28.6 mm 40 mm 10.8 mm 6.7 mm
230737 Gadget
Combination spanners CR-V 21mm GD
Matte 250 mm Cr-V 15 ° No 21 mm 31.7 mm 43 mm 10.6 mm 6.7 mm
230738 Gadget
Combination spanners CR-V 22mm GD
Matte 260 mm Cr-V 15 ° No 22 mm 31.9 mm 44.8 mm 11.5 mm 7.3 mm
230739 Gadget
Combination spanners CR-V 24mm GD
Matte 280 mm Cr-V 15 ° No 24 mm 35.3 mm 52 mm 11.6 mm 7.4 mm
230740 Gadget
Combination spanners CR-V 27mm GD
Matte 305 mm Cr-V 15 ° No 27 mm 39.1 mm 56.7 mm 13.3 mm 8.4 mm
230741 Gadget
Combination spanners CR-V 30mm GD
Matte 335 mm Cr-V 15 ° No 30 mm 43.4 mm 61 mm 14.7 mm 9.6 mm
230742 Gadget
Combination spanners CR-V 32mm GD
Matte 355 mm Cr-V 15 ° No 32 mm 44.9 mm 65.5 mm 14.2 mm 9.8 mm
Description
The Gadget brand includes a wide range of hobby tools, an indispensable part of any hardware or home workshop.

The Gadget Combination Spanners features:

  • Made of chrome-vanadium (CR-V) steel

  • Features a matte body finish
  • >
  • Polished head

  • Standard: DIN 3110

  • Features
    Main characteristics
    Offset ring @ (°) 15 °
    Size (mm) 16 mm
    Length (mm) 200 mm
    Spanner width D1 (mm) 24.2 mm
    Spanner width D2 (mm) 33 mm
    Wrench thickness W2 (mm) 5.9 mm
    Wrench thickness W1 (mm) 8.9 mm
    Material Cr-V
    Coating Matte
    Reverse No
