  • The head of the key is inclined 15 °, convenient for work in inaccessible places
  • Made of high quality chrome vanadium steel
Article number: 235163
Barcode: 3800123114809
Brand: Top Master Pro

DIN
3113
Warranty (years)
30 years
Wrench thickness W1 (mm)
7.2 mm
Wrench thickness W2 (mm)
10.1 mm
Length (mm)
220 mm
Material
Cr-V
Offset ring @ (°)
15 °
Generation
2nd generation
Size (mm)
18 mm
Reverse
No
Spanner width D1 (mm)
37.5 mm
Spanner width D2 (mm)
27.5 mm
Coating
Matte
Series
Art. Number Product Coating DIN Generation Length (mm) Material Offset ring @ (°) Reverse Size (mm) Spanner width D1 (mm) Spanner width D2 (mm) Warranty (years) Wrench thickness W1 (mm) Wrench thickness W2 (mm)
235151 Top Master Pro
Combination spanners 6mm CR-V TMP DIN 3113
Matte 3113 2nd generation 100 mm Cr-V 15 ° No 6 mm 16 mm 10.6 mm 30 years 3.4 mm 4.8 mm
235152 Top Master Pro
Combination spanners 7mm CR-V TMP DIN 3113
Matte 3113 2nd generation 110 mm Cr-V 15 ° No 7 mm 16.8 mm 11.6 mm 30 years 3.6 mm 5.4 mm
235153 Top Master Pro
Combination spanners 8mm CR-V TMP DIN 3113
Matte 3113 2nd generation 115 mm Cr-V 15 ° No 8 mm 18.8 mm 12.8 mm 30 years 3.8 mm 5.6 mm
235154 Top Master Pro
Combination spanners 9mm CR-V TMP DIN 3113
Matte 3113 2nd generation 125 mm Cr-V 15 ° No 9 mm 20.9 mm 14.4 mm 30 years 4.1 mm 6 mm
235155 Top Master Pro
Combination spanners 10mm CR-V TMP DIN 3113
Matte 3113 2nd generation 135 mm Cr-V 15 ° No 10 mm 22.6 mm 16 mm 30 years 4.5 mm 6.3 mm
235156 Top Master Pro
Combination spanners 11mm CR-V TMP DIN 3113
Matte 3113 2nd generation 145 mm Cr-V 15 ° No 11 mm 24 mm 17.2 mm 30 years 4.9 mm 6.8 mm
235157 Top Master Pro
Combination spanners 12mm CR-V TMP DIN 3113
Matte 3113 2nd generation 155 mm Cr-V 15 ° No 12 mm 26.4 mm 18.5 mm 30 years 5 mm 7.2 mm
235158 Top Master Pro
Combination spanners 13mm CR-V TMP DIN 3113
Matte 3113 2nd generation 171 mm Cr-V 15 ° No 13 mm 28.1 mm 20.2 mm 30 years 5.6 mm 8.3 mm
235159 Top Master Pro
Combination spanners 14mm CR-V TMP DIN 3113
Matte 3113 2nd generation 181 mm Cr-V 15 ° No 14 mm 30.1 mm 21.2 mm 30 years 5.7 mm 8.5 mm
235160 Top Master Pro
Combination spanners 15mm CR-V TMP DIN 3113
Matte 3113 2nd generation 185 mm Cr-V 15 ° No 15 mm 32.1 mm 23 mm 30 years 6.1 mm 9.2 mm
235161 Top Master Pro
Combination spanners 16mm CR-V TMP DIN 3113
Matte 3113 2nd generation 195 mm Cr-V 15 ° No 16 mm 34.2 mm 24.4 mm 30 years 6.5 mm 9.3 mm
235162 Top Master Pro
Combination spanners 17mm CR-V TMP DIN 3113
Matte 3113 2nd generation 210 mm Cr-V 15 ° No 17 mm 36 mm 25 mm 30 years 6.8 mm 9.6 mm
235163 Top Master Pro
Combination spanners 18mm CR-V TMP DIN 3113
Matte 3113 2nd generation 220 mm Cr-V 15 ° No 18 mm 37.5 mm 27.5 mm 30 years 7.2 mm 10.1 mm
235164 Top Master Pro
Combination spanners 19mm CR-V TMP DIN 3113
Matte 3113 2nd generation 230 mm Cr-V 15 ° No 19 mm 40.2 mm 28.6 mm 30 years 7.3 mm 10.2 mm
235165 Top Master Pro
Combination spanners 20mm CR-V TMP DIN 3113
Matte 3113 2nd generation 240 mm Cr-V 15 ° No 20 mm 41.4 mm 30.4 mm 30 years 7.4 mm 10.8 mm
235166 Top Master Pro
Combination spanners 21mm CR-V TMP DIN 3113
Matte 3113 2nd generation 245 mm Cr-V 15 ° No 21 mm 43.2 mm 31.8 mm 30 years 7.6 mm 11.1 mm
235167 Top Master Pro
Combination spanners 22mm CR-V TMP DIN 3113
Matte 3113 2nd generation 257 mm Cr-V 15 ° No 22 mm 45.8 mm 33 mm 30 years 7.9 mm 11.7 mm
235168 Top Master Pro
Combination spanners 23mm CR-V TMP DIN 3113
Matte 3113 2nd generation 260 mm Cr-V 15 ° No 23 mm 47.5 mm 34.8 mm 30 years 8.1 mm 12.2 mm
235169 Top Master Pro
Combination spanners 24mm CR-V TMP DIN 3113
Matte 3113 2nd generation 270 mm Cr-V 15 ° No 24 mm 50 mm 36 mm 30 years 8.4 mm 12.8 mm
235170 Top Master Pro
Combination spanners 27mm CR-V TMP DIN 3113
Matte 3113 2nd generation 300 mm Cr-V 15 ° No 27 mm 55 mm 39.5 mm 30 years 9.1 mm 13.9 mm
235171 Top Master Pro
Combination spanners 30mm CR-V TMP DIN 3113
Matte 3113 2nd generation 330 mm Cr-V 15 ° No 30 mm 60.1 mm 43.5 mm 30 years 9.9 mm 15.2 mm
235172 Top Master Pro
Combination spanners 32mm CR-V TMP DIN 3113
Matte 3113 2nd generation 350 mm Cr-V 15 ° No 32 mm 64 mm 46.8 mm 30 years 10.2 mm 15.9 mm
Description
The professional hand tools of Topmaster combine exceptional design, quality & long service life.

Topmaster 18 mm Combination spanner features:

  • The spanner head has an inclination of 15 ° - convenient for work in hard-to-reach places

  • High quality chrome-vanadium (CR- V) steel

  • Durable matt anti-corrosion chrome finish

  • Standardization: DIN 3113

  • Features
    Main characteristics
    Wrench thickness W2 (mm) 10.1 mm
    Offset ring @ (°) 15 °
    Size (mm) 18 mm
    Length (mm) 220 mm
    Spanner width D2 (mm) 27.5 mm
    Generation 2nd generation
    Warranty (years) 30 years
    DIN 3113
    Spanner width D1 (mm) 37.5 mm
    Wrench thickness W1 (mm) 7.2 mm
    Material Cr-V
    Coating Matte
    Reverse No
