  • The head of the key is inclined 15 °, convenient for work in inaccessible places
  • Made of high quality chrome vanadium steel
Article number: 235152
Barcode: 3800123114694
Brand: Top Master Pro

DIN
3113
Warranty (years)
30 years
Wrench thickness W1 (mm)
3.6 mm
Wrench thickness W2 (mm)
5.4 mm
Length (mm)
110 mm
Material
Cr-V
Offset ring @ (°)
15 °
Generation
2nd generation
Size (mm)
7 mm
Reverse
No
Spanner width D1 (mm)
16.8 mm
Spanner width D2 (mm)
11.6 mm
Coating
Matte
Series
Art. Number Product Coating DIN Generation Length (mm) Material Offset ring @ (°) Reverse Size (mm) Spanner width D1 (mm) Spanner width D2 (mm) Warranty (years) Wrench thickness W1 (mm) Wrench thickness W2 (mm)
235151 Top Master Pro
Combination spanners 6mm CR-V TMP DIN 3113
Matte 3113 2nd generation 100 mm Cr-V 15 ° No 6 mm 16 mm 10.6 mm 30 years 3.4 mm 4.8 mm
235152 Top Master Pro
Combination spanners 7mm CR-V TMP DIN 3113
Matte 3113 2nd generation 110 mm Cr-V 15 ° No 7 mm 16.8 mm 11.6 mm 30 years 3.6 mm 5.4 mm
235153 Top Master Pro
Combination spanners 8mm CR-V TMP DIN 3113
Matte 3113 2nd generation 115 mm Cr-V 15 ° No 8 mm 18.8 mm 12.8 mm 30 years 3.8 mm 5.6 mm
235154 Top Master Pro
Combination spanners 9mm CR-V TMP DIN 3113
Matte 3113 2nd generation 125 mm Cr-V 15 ° No 9 mm 20.9 mm 14.4 mm 30 years 4.1 mm 6 mm
235155 Top Master Pro
Combination spanners 10mm CR-V TMP DIN 3113
Matte 3113 2nd generation 135 mm Cr-V 15 ° No 10 mm 22.6 mm 16 mm 30 years 4.5 mm 6.3 mm
235156 Top Master Pro
Combination spanners 11mm CR-V TMP DIN 3113
Matte 3113 2nd generation 145 mm Cr-V 15 ° No 11 mm 24 mm 17.2 mm 30 years 4.9 mm 6.8 mm
235157 Top Master Pro
Combination spanners 12mm CR-V TMP DIN 3113
Matte 3113 2nd generation 155 mm Cr-V 15 ° No 12 mm 26.4 mm 18.5 mm 30 years 5 mm 7.2 mm
235158 Top Master Pro
Combination spanners 13mm CR-V TMP DIN 3113
Matte 3113 2nd generation 171 mm Cr-V 15 ° No 13 mm 28.1 mm 20.2 mm 30 years 5.6 mm 8.3 mm
235159 Top Master Pro
Combination spanners 14mm CR-V TMP DIN 3113
Matte 3113 2nd generation 181 mm Cr-V 15 ° No 14 mm 30.1 mm 21.2 mm 30 years 5.7 mm 8.5 mm
235160 Top Master Pro
Combination spanners 15mm CR-V TMP DIN 3113
Matte 3113 2nd generation 185 mm Cr-V 15 ° No 15 mm 32.1 mm 23 mm 30 years 6.1 mm 9.2 mm
235161 Top Master Pro
Combination spanners 16mm CR-V TMP DIN 3113
Matte 3113 2nd generation 195 mm Cr-V 15 ° No 16 mm 34.2 mm 24.4 mm 30 years 6.5 mm 9.3 mm
235162 Top Master Pro
Combination spanners 17mm CR-V TMP DIN 3113
Matte 3113 2nd generation 210 mm Cr-V 15 ° No 17 mm 36 mm 25 mm 30 years 6.8 mm 9.6 mm
235163 Top Master Pro
Combination spanners 18mm CR-V TMP DIN 3113
Matte 3113 2nd generation 220 mm Cr-V 15 ° No 18 mm 37.5 mm 27.5 mm 30 years 7.2 mm 10.1 mm
235164 Top Master Pro
Combination spanners 19mm CR-V TMP DIN 3113
Matte 3113 2nd generation 230 mm Cr-V 15 ° No 19 mm 40.2 mm 28.6 mm 30 years 7.3 mm 10.2 mm
235165 Top Master Pro
Combination spanners 20mm CR-V TMP DIN 3113
Matte 3113 2nd generation 240 mm Cr-V 15 ° No 20 mm 41.4 mm 30.4 mm 30 years 7.4 mm 10.8 mm
235166 Top Master Pro
Combination spanners 21mm CR-V TMP DIN 3113
Matte 3113 2nd generation 245 mm Cr-V 15 ° No 21 mm 43.2 mm 31.8 mm 30 years 7.6 mm 11.1 mm
235167 Top Master Pro
Combination spanners 22mm CR-V TMP DIN 3113
Matte 3113 2nd generation 257 mm Cr-V 15 ° No 22 mm 45.8 mm 33 mm 30 years 7.9 mm 11.7 mm
235168 Top Master Pro
Combination spanners 23mm CR-V TMP DIN 3113
Matte 3113 2nd generation 260 mm Cr-V 15 ° No 23 mm 47.5 mm 34.8 mm 30 years 8.1 mm 12.2 mm
235169 Top Master Pro
Combination spanners 24mm CR-V TMP DIN 3113
Matte 3113 2nd generation 270 mm Cr-V 15 ° No 24 mm 50 mm 36 mm 30 years 8.4 mm 12.8 mm
235170 Top Master Pro
Combination spanners 27mm CR-V TMP DIN 3113
Matte 3113 2nd generation 300 mm Cr-V 15 ° No 27 mm 55 mm 39.5 mm 30 years 9.1 mm 13.9 mm
235171 Top Master Pro
Combination spanners 30mm CR-V TMP DIN 3113
Matte 3113 2nd generation 330 mm Cr-V 15 ° No 30 mm 60.1 mm 43.5 mm 30 years 9.9 mm 15.2 mm
235172 Top Master Pro
Combination spanners 32mm CR-V TMP DIN 3113
Matte 3113 2nd generation 350 mm Cr-V 15 ° No 32 mm 64 mm 46.8 mm 30 years 10.2 mm 15.9 mm
Description
The professional hand tools of Topmaster combine exceptional design, quality & long service life.

Topmaster 7 mm Combination spanner features:

  • The spanner head has an inclination of 15 ° - convenient for work in hard-to-reach places

  • High quality chrome-vanadium (CR- V) steel

  • Durable matt anti-corrosion chrome finish

  • Standardization: DIN 3113

  • Features
    Main characteristics
    Spanner width D2 (mm) 11.6 mm
    Length (mm) 110 mm
    Offset ring @ (°) 15 °
    Spanner width D1 (mm) 16.8 mm
    Generation 2nd generation
    Wrench thickness W1 (mm) 3.6 mm
    Warranty (years) 30 years
    DIN 3113
    Wrench thickness W2 (mm) 5.4 mm
    Size (mm) 7 mm
    Material Cr-V
    Coating Matte
    Reverse No
